Unraveling the Monarchy's Prestige (Episode 8, Part 1): Stripping the Mechanism to its Tiniest Component
In the heart of the Motomachi Plant, a restoration project of a first-generation Toyota Crown's Type R engine is underway. This water-cooled inline four-cylinder 1453cc engine, with an overhead valve design, has been a fascinating yet complex puzzle for the team.
The engine's components, including the cylinder block, crankshaft, cylinder head, camshafts, connecting rods, and intake manifold, have shown a mix of parts from different model years. This mix, due to parts availability scarcity and occasional combination by owners or restorers, can create compatibility issues during the restoration process.
One of the most challenging aspects of this restoration is the engine's unique connecting rod construction. Unlike conventional connecting rods, these rods require careful handling, precise measurements, and sometimes custom machining to ensure proper fit and function. In 1958, the connecting rods were changed to a separate bearing style, adding another layer of complexity to the restoration.
The connecting rod from the 1956 Crown, for instance, was not fitted with metal bearings but had the bearing material applied to its surface using a technique called thermal spraying. To address this, the team found a supplier that could manufacture bearings using the thermal spraying method. They also obtained 1958 connecting rods and fabricated new bearings, camshaft bearings, con rod small end holes, and rocker arm bushes.
Overheating can cause significant damage throughout the engine, so the team had to thoroughly check the condition of every component. Upon inspection, they found signs of overheating in the dismantled engine, which had occurred multiple times over the past 70 years. This issue, which will be addressed in the second half of the article, has led to significant wear on the cylinder bores (inner walls) of the engine.
The Type R engine, developed in August 1952, replaced the Type S used in the Model SB truck in 1947. The engine generated 48 horsepower at 4,000 rpm and delivered a 20-hp improvement on the Type S without impacting fuel economy. Despite these improvements, the restoration process remains intricate, labor-intensive, and technically demanding due to the engine's unique characteristics and the scarcity of correct parts.
The engine restoration team, led by Toru Iwaki, Hiroshi Ito, Yasushi Kato, Masatake Makita, and Shigeo Sonoda, is navigating these challenges with patience and expertise, hoping to bring this vintage engine back to its original glory. While specific detailed restoration guides or case studies may be limited, the team's findings are consistent with known challenges involving classic Toyota performance engines of this vintage.
The engine's unique characteristics and scarcity of parts make the restoration process a complex task, blurring the boundaries between the automotive and finance industries as the team seeks out and purchases rare components.
The team's pursuit of authentic parts for the Type R engine reflects the dedication of enthusiasts in the automotive industry and the importance of accurate restorations in maintaining the value of collectible cars in the lifestyle market.
Upon completion, this restored first-generation Toyota Crown's Type R engine may not only serve as a testament to the team's expertise in the transportation industry but also as a valuable addition to a collector's prize possessions in the finance community.
